Hexagon locknut
Hexagon locknut
| Part-no. | Description | Thread | D | L | S | Type | Weight |
|---|---|---|---|---|---|---|---|
| 65-1 | Locknut - standard | M 24 x 3 re | 36 | 61 | 8 | C | 0.084 kg |
| 65-10 | Locknut star-delta | M 27 x 3 re | 43 | 44 | 18 | B | 0.160 kg |
| 65-11 | Hexagon locknut | M 30 x 3,5 re | 46 | — | 11,5 | A | 0.102 kg |
| 65-12 | Locknut - standard | M 24 x 2,5 li | 36 | 41 | 8 | C | 0.070 kg |
| 65-13 | Hexagon locknut | M 30 x 3,5 li | 46 | — | 12 | A | 0.100 kg |
| 65-14 | Hexagon locknut | M 30 x 3,5 re | 46 | — | 24 | A | 0.210 kg |
| 65-15 | Hexagon locknut | M36x3 right | 54 | — | 29 | A | 0.340 kg |
| 65-16 | Hexagon locknut | M 30 x 3,5 li | 45 | — | 24 | A | 0.200 kg |
| 65-17 | Hexagon locknut | M 36 x 3 li | 55 | — | 29 | A | 0.360 kg |
| 65-18 | Hexagon locknut | M 24 x 3 re | 36 | — | 10 | A | 0.050 kg |
| 65-19 | Locknut - standard | M 30 x 3,5 li | 45 | 60 | 6 | C | 0.090 kg |
| 65-2 | Locknut - standard | M27 x 3 | 43 | 58 | 8 | C | 0.100 kg |
| 65-20 | Hexagon locknut | M 36 x 4 re | 54 | — | 29 | A | 0.350 kg |
| 65-21 | Hexagon locknut | M 24 x 3 re | 36 | — | 18,5 | A | 0.100 kg |
| 65-22 | Locknut - standard | M 40 x 3 re | 60 | 88 | 10 | C | 0.230 kg |
| 65-23 | Locknut star-delta | M 36 x 3 li | 50 | 45 | 18 | B | 0.200 kg |
| 65-24 | Hexagon locknut | M24x3 left | 35,5 | — | 9,5 | A | 0.050 kg |
| 65-25 | Hexagon locknut | 1 3/4" right | 70 | — | 30 | A | 0.663 kg |
| 65-26 | Hexagon locknut | 1 3/4" left | 70 | — | 30 | A | 0.660 kg |
| 65-28 | Hexagon locknut | M24x3 left | 35 | — | 18 | A | 0.100 kg |
| 65-29 | Hexagon locknut | M27x3 right | 40 | — | 21 | A | 0.144 kg |
| 65-3 | Locknut star-delta | M 30 x 3 re | 42 | 45 | 18 | B | 0.140 kg |
| 65-30 | Locknut - standard | M24x3 right | 36 | 41 | 8 | C | 0.064 kg |
| 65-31 | Locknut - standard | M36x3 left | 55 | — | 14 | A | 0.176 kg |
| 65-32 | Hexagon locknut | M16x2 left | 24 | — | 12,5 | A | 0.030 kg |
| 65-33 | Hexagon locknut | M20x2,5 | 30 | — | 9 | A | 0.033 kg |
| 65-4 | Locknut - standard | M 30 x 3,5 re | 41 | 41 | 8 | C | 0.100 kg |
| 65-40 | Hexagon locknut | M27x3 ri. | 40 | — | 11,5 | A | 0.081 kg |
| 65-5 | Locknut star-delta | M 36 x 3 re | 49 | 54 | 23 | B | 0.200 kg |
| 65-7 | Locknut star-delta | M 40 x 3 re | 50 | 55 | 23 | B | 0.210 kg |
| 65-8 | Locknut star-delta | M 30 x 3,5 re | 42 | 45 | 18 | B | 0.146 kg |
| 65-9 | Locknut - standard | M 24 x 2,5 re | 36 | 41 | 8 | C | 0.066 kg |
| 657-701 | Hexagon locknut | M24x3 | — | — | — | — | 0.096 kg |
The trade mark has been placed in our illustrations with the sole aim of protecting our illustrations as part of our intellectual property.
| Part-no. | 65-19 |
| Weight | 0.090 kg |
| Thread | M 30 x 3,5 li |
| D | 45 |
| L | 60 |
| S | 6 |
| Type | C |
Part fitting for machine…
| Adaptable for | Orig.part n° |
|---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
