Part-no. | 659-01 |
Weight | 11.890 kg |
H | 150 |
D | 52 |
A | 325 |
L | 380 |
G | 60 |
B | 125 |
D1 | 82 |
D2 | 62 |
Max. supporting load | 3000 DaN |
Max. tensile load | 17000 DaN |
G1 | M42 x 4,5 |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-0201 |
Weight | 12.400 kg |
H | 149,5 |
D | 50 |
A | 367 |
L | 427 |
G | 49 |
B | 120 |
D1 | 82 |
Max. supporting load | 2800 kg |
Notice | ISO 5692-3:2011 |
G1 | M42x4,5 |
Permitted D-value | 84,1 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-025 |
Weight | 12.950 kg |
Thread | M52 x 5 |
H | 150 |
D | 52 |
A | 335 |
L | 395 |
G | 61 |
B | 123 |
D1 | 82 |
D2 | 62 |
Max. supporting load | 3500 DaN |
Max. tensile load | 25000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-052 |
Weight | 7.921 kg |
Material | ST52-3 |
Max. supporting load | 1500 DaN |
Max. tensile load | 10000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-054 |
Weight | 3.780 kg |
Material | ST52-3 |
Max. supporting load | 700 DaN |
Max. tensile load | 2500 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-055 |
Weight | 5.516 kg |
H | 300 |
D | 40 |
L | 350 |
B | 10 |
Material | ST52-3 |
C | 50 |
Max. supporting load | 1000 DaN |
Max. tensile load | 5000 DaN |
E | 50 |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-1122 |
Weight | 3.847 kg |
Material | ST52 |
Length | 280 |
Max. supporting load | 1100 DaN |
Max. tensile load | 10000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-1125 |
Weight | 4.927 kg |
Material | ST52 |
Length | 280 |
Max. supporting load | 2000 DaN |
Max. tensile load | 14000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-1204 |
Weight | 7.138 kg |
Material | ST52 |
Length | 300 |
Max. supporting load | 3000 DaN |
Max. tensile load | 14000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-1209 |
Weight | 7.930 kg |
Material | ST52 |
Length | 340 |
Max. supporting load | 3000 DaN |
Max. tensile load | 25000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-12550 |
Weight | 5.020 kg |
Material | ST52 |
Length | 340 |
Max. supporting load | 1100 DaN |
Max. tensile load | 7000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-1329 |
Weight | 9.500 kg |
Material | 30MnCrB5 |
Length | 340 |
Max. supporting load | 3000 kg |
Notice | ISO 20019 |
Permitted D-value | 98,9 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-30151 |
Weight | 4.800 kg |
H | 135,3 |
D | 35 |
A | 287,5 |
G | 38,2 |
B | 97 |
Length | 336 |
D1 | 51 |
D2 | 40,5 |
Max. supporting load | 700 kg |
Notice | ISO 5692/3:2011 |
G1 | M30x3,5 |
Permitted D-value | 21,4 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-30161 |
Weight | 6.360 kg |
H | 145,3 |
D | 35 |
A | 255 |
L | 350 |
G | 38,5 |
B | 95 |
D1 | 60 |
D2 | 47,5 |
Max. supporting load | 1250 kg |
Notice | ISO 5692-3:2011 |
G1 | M33x3,5 |
Permitted D-value | 33,4 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-30211 |
Weight | 7.240 kg |
H | 135 |
D | 50 |
A | 270 |
L | 390 |
G | 42 |
B | 120 |
D1 | 60 |
Max. supporting load | 1000 kg |
Notice | ISO 5692-3:2011 |
G1 | M33x3,5 |
Permitted D-value | 36,5 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-30248 |
Weight | 7.480 kg |
H | 135 |
D | 50 |
A | 330 |
L | 390 |
G | 40,5 |
B | 120 |
D1 | 60 |
Max. supporting load | 1600 kg |
Notice | ISO 5692-3:2011 |
G1 | M33x3,5 |
Permitted D-value | 45,8 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-31209 |
Weight | 8.083 kg |
Length | 340 |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-36002 |
Weight | 5.670 kg |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-36040 |
Weight | 22.000 kg |
Material | 33MnCrB5 |
Length | 322 |
Max. supporting load | 4000 kg |
Notice: | ISO 24347:2005 |
Permitted D-value | 100 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-43 |
Weight | 2.580 kg |
Thread | M24 x 3 |
H | 120 |
D | 32 |
A | 230 |
L | 270 |
G | 30 |
B | 80 |
D1 | 42 |
D2 | 31 |
Max. supporting load | 450 DaN |
Max. tensile load | 2000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-44 |
Weight | 4.160 kg |
Thread | M30 x 3,5 |
H | 130 |
D | 45 |
A | 295 |
L | 345 |
G | 30 |
B | 97 |
D1 | 48 |
D2 | 38 |
Max. supporting load | 900 DaN |
Max. tensile load | 4000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-45 |
Weight | 5.420 kg |
Thread | M30 x 3,5 |
H | 140 |
D | 45 |
A | 300 |
L | 345 |
G | 45 |
B | 96 |
D1 | 57 |
D2 | 44 |
Max. supporting load | 1500 DaN |
Max. tensile load | 6000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-47 |
Weight | 6.750 kg |
Thread | M33 x 3,5 |
H | 160 |
D | 45 |
A | 320 |
L | 370 |
G | 40 |
B | 100 |
D1 | 60 |
D2 | 47 |
Max. supporting load | 2050 DaN |
Max. tensile load | 7500 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-48 |
Weight | 5.980 kg |
Thread | M33 x 3,5 |
H | 135 |
D | 52 |
A | 265 |
L | 325 |
G | 45 |
B | 120 |
D1 | 58 |
D2 | 44 |
Max. supporting load | 2000 DaN |
Max. tensile load | 8000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-50 |
Weight | 13.100 kg |
Thread | M42 x 4,5 |
H | 150 |
D | 52 |
A | 320 |
L | 390 |
G | 65 |
B | 130 |
D1 | 83 |
D2 | 62 |
Max. supporting load | 3000 DaN |
Max. tensile load | 12000 DaN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-5225 |
Weight | 13.440 kg |
H | 149,5 |
D | 50 |
A | 367 |
L | 427 |
G | 61 |
B | 120 |
D1 | 82 |
Max. supporting load | 3000 kg |
Notice | ISO 5692-3:2011 |
G1 | M52x5 |
Permitted D-value | 91 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-6001 |
Weight | 11.340 kg |
Material | 33MnCrB5 |
Length | 293 |
Max. supporting load | 2500 kg |
Notice | ISO 5692/2 |
Permitted D-value | 89,7 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
Part-no. | 659-6020 |
Weight | 22.580 kg |
Material | 33MnCrB5 |
Length | 293 |
Max. supporting load | 3000 kg |
Notice | ISO 20019 |
Permitted D-value | 100 kN |
Adaptable for | Orig.part n° |
---|
IHOF spare parts are non-genuine parts. All references to original brand descriptions and part numbers are made only for the sake of comparison.
The unauthorized use of the drawings depicted,
constitutes an infringement of copyright and will be prosecuted by us.
The trade mark has been placed in our illustrations with the sole aim of protecting our illustrations as part of our intellectual property.
