Torsion spring
Torsion spring right
| Part-no. | 1.10.23109 |
| Weight | 0.440 kg |
| Wire diameter | 7 |
| Coil diameter internal | 54 |
Part fitting for machine…
No original parts. Manufacturer's designations and original parts numbers are provided for comparison purposes only. The dimensions and weights are approximate and non-binding. Subject to technical changes.
Torsion spring left
| Part-no. | 1.10.23110 |
| Weight | 0.440 kg |
| Wire diameter | 7 |
| Coil diameter internal | 54 |
Part fitting for machine…
No original parts. Manufacturer's designations and original parts numbers are provided for comparison purposes only. The dimensions and weights are approximate and non-binding. Subject to technical changes.
Torsion spring
| Part-no. | 1.10.23122 |
| Weight | 0.042 kg |
| Wire diameter | 7 |
| Coil diameter internal | 50 |
No original parts. Manufacturer's designations and original parts numbers are provided for comparison purposes only. The dimensions and weights are approximate and non-binding. Subject to technical changes.
